- DELTA® Flush Valve, Series: 81TBT/81THW, Urinal Fixture, Hardwired Power Source, 8 gpm Flush, 1 in FNPT or 3/4 in C Inlet, 25 psi Pressure, Electronic Handle, Matte Black
- Urinal, 13" height
- Hardwire models, order transformer separately
- Electronic exposed flush valve
- Hands-free operation
- Body mounted sensor
- Vacuum breaker
- 3/4" copper sweat inlet
- Infrared sensor range adjustment of 203 mm to 610 mm (8 to 24 in), factory set at 16 in (+/-2 in)
- Set-up sensor range adjustment indicator lights
- 6 VDC input, 6 s arming delay
- Electronic operated non-hold-open metal manual override button with 5 sec lockout
- Quiet action, TECK® exposed diaphragm flush valve
- Chloramine resistant diaphragm
- Brass diaphragm retainer
- Renewable seat
- 1 in FNPT/3/4 in C inlet adaptor, angle check stop with protecting cap
- Factory set to 0.5 L (0.125 gal) not field adjustable
- Finish / ColorMatte BlackFlush Rate8 gpmInlet Size1 in FNPT or 3/4 in CPower SourceHardwiredPressure Rating25 psiFixture TypeUrinalHandle TypeElectronicManufacturerDelta Faucet CompanyManufacturer #81T231HWA-05-MMO-BLSeries81TBT / 81THW
