Honeywell Home
Honeywell Home VU443A1008/U VU443A 2-Position Actuator, 0.4" Stroke, Stainless Steel/Aluminum Body
Sign In to View Pricing & Availability
- The humidity resistant, fan Coil Valve Actuators are used in conjunction with VU52, VU53 and VU54 valves for controlling the flow of hot or chilled water in commercial HVAC equipment such as fan coil units, terminal reheat coils and convectors.
Honeywell Home, VU443A1008/U, Actuator, 2-Position, Series: VU443A, 0.4" Stroke, 2-Way Valve Design, 6 W Power Consumption, 15 sec Timing, 24 VAC Floating Signal, 120 V Supply, 6" Lead Wire Electrical Connections, 32 to 150 deg F, Stainless Steel/Aluminum Body, For Use With: VC Series Valves/1000 Series 2-way/6000 Series 3-way, Nickel-Plated
- Compact construction for easy installation
- Fits under the cover of most baseboard convectors with actuator fitted to valve body
- One-button, quick release
- Secure 3-point, metal latch to valve body
- Spring return operation
- Stainless steel case and aluminum cover
- Rust-proof nickel-plated motors available
- Line or low voltage, rust-resistant motors
- Manual opener for installation and valve operation on power failure
- Valve returns to automatic position when power is restored
- Actuator may be reinstalled or serviced without draining the system or disassembling the valve
- Slotted conduit hole for faster wiring
- Body MaterialStainless Steel/AluminumSeriesVU443AStroke0.4 inType2-PositionElectrical Connections6 in Lead WireFinishNickel-PlatedManufacturerResideo TechnologiesManufacturer #VU443A1008/UPower Consumption6 WPower Supply120 VSignal Type24 V FloatingTemperature Rating32 to 150 deg FTiming15 secValve Design2-Way
