Smith-Blair 663-111004MJ-000 #663 Tapping Sleeve, 10x4", Mechanical Joint Connection, Stainless Steel Clamp, Flexi-Coat® Fusion Bonded Epoxy Coated
Sign In to View Pricing & Availability
- Smith-Blair Tapping Sleeves consist of two sections of heavy welded steel that bolt together on the pipe and seal against a concave wedge gasket around the tap opening.
- Easy to install
- Range helps reduce inventory
- Molded-in ring in the gasket to ensure effective sealing
- Nylon washers are provided to improve bolt torque capability
- Heavy gauge, all stainless steel body for rugged performance
- Fully chemically passivated for maximum corrosion protection
- 360 deg seal provides maximum support and reinforcement around the pipe in case of pipe break
- Body drawn out to accept the outlet neck adding to the overall strength of the area under the most stress
- The MJ outlet allows the user to tap pipe, utilizing a standard MJ x MJ valve in lieu of a specialty tapping valve
- This outlet allows the user to combine valve inventory to a single valve, reduce installation time and save money
- The heavy mechanical joint flange is fixed in place to make installation easier, while reducing the chance of injuries during the tapping operation
- 12 ga 304 Stainless Steel Top Plate, 16 ga 304 Stainless Steel Bottom Plate, 3/4 in NPT 304 Stainless Steel Neck, 304 Stainless Steel Flange/Bridge Plate, 10 ga 304 Stainless Steel Finger/Lug Bar, 14 ga 304 Stainless Steel Keeper Bar, 1/4 in Nitrile (Buna-N) Gasket, 5/8 in Nylon/304 Stainless Steel Washers, 5/8-11 UNC 304 Stainless Steel Nuts, Test Outlet and (8) 5/8 in 304 Stainless Steel Bolts
- Clamp Material18-8 304 Stainless SteelConnection TypeMechanical JointFinishFlexi-Coat Fusion Bonded Epoxy CoatedNominal Size10 x 4 inBolt Material18-8 304 Stainless SteelBolt Size5/8-11 UNC x 6 in LGasket MaterialBuna-NManufacturerXylemManufacturer #663-111004MJ-000Pressure Rating240 psiSeries663Temperature Rating180 deg F
