0013-MSF2-IFC 3 Speed Circulator Pump, High Flow, Cast Iron, Rotated Flange

TAC0013MSF2IFC MFG #: 0013-MSF2-IFC
  • Flow Rate: 30 gpm
  • Voltage Rating: 115V
  • Amperage: 1.65
  • Connection Size: 3/4, 1, 1-1/4, 1-1/2 in
  • Connection Type: Rotated Flange
  • Dimensions: 6-1/2 in H x 9-7/16 in W x 6-9/64 in D
  • Frequency Rating: 60 Hz
  • Manufacturer: TACO
  • Manufacturer #: 0013-MSF2-IFC
  • Material: Cast Iron
  • Max Head: 30 ft
  • Phase: 1
  • Pressure Rating: 125 psi
  • Series: 0013
  • Speed: 3250 rpm
  • Temperature Rating: 210 degF
The high-performance 0013 3-Speed circulator is designed for high-head/high-flow, large residential/light commercial hydronic heating and chilled water cooling systems. The 3-Speed switching ability lets you fine tune the performance to match a wide range of applications. The Stainless steel 0013 3-Speed is best suited for potable water and hot water recirculation systems. The 0013 3-Speed directly replaces a Grundfos UPS26-99 3-Speed.

  • Features
  • 3-Speed Switch
  • Fine tune to system requirements
  • Highest performance & starting torque in class
  • Heavy-Duty construction for longer life
  • Removable high-flow Integral Flow Check (IFC®
  • Replaceable cartridge design
  • Quiet, efficient operation
  • Self lubricating, no mechanical seal
  • Wide range of applications
