- The Trerice D80 Series Industrial Gauge is designed for rugged performance requirements at an economical cost. This liquid-filled gauge is furnished with a stainless steel case and crimped ring. Wetted parts are either bronze tube with Lead-Free (PBF) brass socket or stainless steel.
Trerice Industrial Pressure Gauge, Series: D80, 30" Hg to 0, 1/8 in MNPT, 1-1/2 in Dial Diameter, +/- 1.6 % Accuracy, Liquid Filled: Glycerin, 150 deg F, Back Mount, 304 Stainless Steel Case, 1.85 in Dia x 1.06 in D
- Brass movement
- Plain, black finished pointer
- Bronze tube, brass socket
- Acrylic window
- 304 stainless steel, stem mounted flangeless case
- Aluminum/white background with black graduations and markings dial face
- Crimped 304 stainless steel ring
- Accuracy+/- 1.6 %Connection Size1/8 inDial Diameter1-1/2 inPressure Range30" Hg to 0TypeLiquid FilledBody MaterialStainless SteelConnection TypeMNPTDimensions1-7/8 in Dia x 1-1/8 in DLiquid FilledGlycerinManufacturerH. O. TrericeManufacturer #D82LFB1501BA30/0Material304 Stainless Steel CaseMounting TypeBackSeriesD80Temperature Rating150 deg FUnit of Measurepsi
