- The Model 74 is an Anti-Siphon Vacuum Breaker protected wall hydrant housed in a tamper resistant brass box. The hydrant is designed for use in mild climate areas or within temperature controlled malls and plazas.
Woodford® Close Coupled Wall Hydrant, Anti-Siphon, 3/4 in Nominal, C, 125 psi, 120 deg F, Brass, Chrome Plated, 6-1/2 in H
- Nidel® model 34HF vacuum breaker with 3/4 in male hose thread nozzle
- Permanent type brass valve body with hemispherical seating surface
- No lead solder on all solder joints
- Hardened stainless steel stem resists damage
- EPDM rubber packing with adjustable packing nut
- Loose key operates hydrant
- Concealed box type wall hydrant
- For non-freezing areas only
- Model B74
- End StyleCNominal Size3/4 inPressure Rating125 psiDimensions6-1/2 in HFinishChrome PlatedManufacturerWoodford ManufacturingManufacturer #B74C-CHMaterialBRASSTemperature Rating120 deg FTypeAnti-Siphon
